PB10 Pipe Beveling Machine (Pneumatic or Electric)

The Steelmax PB10 pipe beveling machine is designed for portable use in pipe machining operations and can be used efficiently by a single operator. The PB10 is a heavy-duty ID mounted pipe beveler utilizing self-centering expandable mandrels to provide quick and proper alignment to a pipe or a tube prior to machining operations.

The PB10 is able to bevel, face and counter-bore in a single operation, making all these weld prep operations quick and simple.

Depending on preferences and site conditions, the PB10 can be operated with a powerful pneumatic motor or a high-torque electric motor.

FEATURES

  • Bevel, face and counter-bore simultaneously
  • Standard and custom made tool bits available
  • Available in electric and pneumatic versions
  • J-Bevel tool bits available for high welding efficiency on thicker walled pipe
SKU: SM-PB10-E; SM-PB10-P Categories: ,

Product Description

PB10 Technical Specifications
Pipe Machine RangeMin I.D. – 1.6" (40 mm)
Max I.D. – 10-9/16” (269 mm)
Wall thickness: up to .80" (20 mm)
Part numberSM-PB10
- Pneumatic motor1500W 2.0 HP
- Power requirements1750 l/min (61.7 cfm) at 630 kpa (90 psi)
- Headstock speed range5 to 19 rpm
Part numberSM-PBE10
- Electric motor1800W
- Supply115V/60Hz or 230V/50Hz
- Headstock speed range14 to 32 rpm
Additional Equipment:
SM-PRK-0447-00-00-00-2Flange facing attachment with cutting capacities 3-9/16” to 20" (90 - 508 mm), delivered in a metal boxPB10-Pipe-Beveling-Machine-Accessories
SM-PRK-0463-00-00-00-1Out of round attachment set includes large mandrel for pipe ID Ø 5" to 11-5/8" (126 - 296 mm), delivered in a metal box
SM-ZSP-0200-05-00-00-2Self-centering expandable Mandrel for pipe I.D. Ø 1-1/2 – 3-3/8” (38 – 86 mm)
SM-ZST-0200-13-00-00-2Extension set for ID Ø up to 14” (355 mm) includes 3 steel tool holders and jaws 7-12, delivered in metal box
SM-ZST-0200-12-00-00-0
SM-ZST-0200-12-00-00-1
SM-ZSP-0200-03-00-00-0
Electric motor set 230V
Electric motor set 115V US plug
Air Motor Assembly
